adarsh industries - manufacturer of pressure gauges, temperature gauges and gauge accessories
Since 1989
For Inquiry CALL +91-22-29275496
Adarsh Ammonia Gauges are specially designed to sustain against vibration, sudden pressure and temperature conditions. Ammonia gauge are used to measure suction and discharge pressure on Ammonia compressors.


4 Availalble in dial sizes 2-1/2", 4"
4 Complete Stainless Steel Construction
4 Dry or Liquid Filled (Glycerin or Silicon)
4 Any standard thread connection
4 Bottom or Back Mounted

Download Datasheets                                       Series

63mm (2-1/2") Dial Size SS Ammonia Gauge........................AM102
100mm (4") Low Cost Model SS Ammonia Gauge.................AM30X
100mm (4") Heavy Duty Model SS Ammonia Gauge..............AM40X

Options Available

4 Custom Designed Dials
4 Accessories: Pulsation Dampner, Gauge Cocks, Gauge Savers

Pressure Range Selection

All Pressure Scales are with corresponding temperature readings

psi scale                     bar scale           kg/cm2 scale
-30x150 psi                -1x9 bar            -760mmhg x 16 kg/cm2
-30x300 psi                -1x12 bar          -760mmhg x 25 kg/cm2
                                   -1x15 bar
                                   -1x25 bar

How to Inquire:

Send you inquiry with details like :
4Dial size - 2-1/2" or 4"
4Pressure range - select range from above
4Thread connection - 1/4" npt or 3/8" or 1/2" bsp/npt
4Mounting: bottom or back
4Filling: dry or liquid (glcyerin or silicon) filled
or any other special requirements you have.

Send Email to 4 or 4Click here to send inquiry by online form Or Call +91-22-29275496 Fax +91-22-29275558

Ammonia Pressure Gauges
AM Series
Model: AM401
4" SS Heavy Duty Ammonia Gauge

Model: AM102
2-1/2" SS Ammonia Gauge

Ammonia Pressure Gauge
Ammonia Gauge
Ammonia Gauge
Model: AM301
4" SS Economical Ammonia Gauge


Adarsh Industries
307, Shankala Industrial Estate,
Gogatewadi, Off Aarey Road,
Goregaon East,
Mumbai - 400063
Tel: +91-22-29275496, Fax: +91-22-29275558

Dont  buy cheap ammonia gauges, it could lead to leakage of ammonia in your plant which could be dangerous. Always prefer ADARSH Stainless Steel Ammonia Gauges for longer use. It features a Glycerin Filled Stainless Steel Case with Argon Welded SS316 wetted parts. Available in both bottom and back connections. Call +91-22-29275496 or email at . The gauges are available in all major Indian cities through our dealers and across the globe too.
