Capsule Pressure Gauges India

Capsule Pressure Gauges are suitable for measuring low pressure of gases from ranges 400mmwc to 6000mmwc. (40mbar to 600mbar)

Specifications

4Available in Dial Sizes 100mm (4") & 150mm (6")

4 Ranges from 400mmwc to 6000mmwc (600mbar)

4 SS316 / Brass Diaphragm Capsule

4 Stainless Steel Case and ring

4 Standard Thread Connections

4 Bottom or Back Mounted

Download Datasheets Series

100mm Capsule Pressure Gauges.....................................DK100

150mm Capsule Pressure Gauges.....................................DK150

Applications

Measurement of Low Pressure of Gaseous Media eg. Burner Monitoring, Gas Production, Medical Applications, etc

Options Available

4 Inbuilt Over Pressure Protection - 5 times of max pressure

4 Accessories: Over Pressure Protector, Dampners,

4 Scales in mmwc, mbar, mmhg, inhg

4 Custom designed dials

Pressure Range Selection

mmwc or mbar

0-400 0-40

0-600 0-60

0-1000 0-100

0-1500 0-150

0-2000 0-200

0-3000 0-300

0-4000 0-400

0-5000 0-500

0-6000 0-600

Also available in mmhg, inhg scales

How to Inquire:

Send you inquiry with details like :

4dial size: 100mm (4") & 150mm (6")

4pressure range: any std range

4thread connection: 3/8" or 1/2" bsp or npt

4mounting: bottom or back

4application media (gas) or any other special information you have.
