HIGH ACCURACY DIGITAL PRESSURE GAUGE
Ideal for Calibration and High Accuracy Applications
Features
3" / 4" dial size
High Accuracy, High Resolution, High Precision
0.1%, 0.075%, 0.05% F.S. Accuracy
Selectable Units: kg/cm2, bar, psi, mmhg, mmwc, kpa, mbar
Wetted parts SS316
Ranges from 0-1 bar upto 700 bar, vacuum & compound
Customized Pressure Ranges
Accessories: Pulsation Dampner, Syphons, Diaphragm Seals, Gauge Cocks, Gauge Savers
Pressure Ranges
0-1, 0-2, 0-7, 0-10, 0-20, 0-35, 0-70, 0-100, 0-200, 0-350, 0-400, 700 kg/cm2 or bar
-1x0 (vacuum) & compound ranges -1x7, -1x20, -1x35 bar / kg/cm2
Or any custom range as required.
Also available in mmwc ranges
Cannot measure pressure with fine precision by mechanical gauges, switch to Digital Pressure Gauges from ADARSH and measure pressure more accurately & precisely. Get accuracy upto six times more compared to analog gauges and high resolution with least count upto 0.001 kg/cm2 / bar. Ideal for laboratory use, pressure gauge calibration and applications requiring high accuracy, precision and repeatability.
Digital Pressure Gauges
Since 1989
India
LOW COST DIGITAL PRESSURE GAUGE
Ideal for Replacing Analog Gauges
Features
Low Cost
Accuracy < ± 0.5% F.S.
Pressure Ranges upto 700 bar
Measurement Units: PSI, BAR, kg/cm2
Available Ready Stock
Other Specifications
Over Range Protection: 2X Rated Pressure
Burst Pressure: 5X or 20,000 PSI whichever is less
Pressure Cycles: >100 Million
Operating (Ambient): -10°C to 60°C
Storage: -20°C to 70°C
Display: 0.6†LCD display and blue Backlight
Power 9 Volt Alkaline Battery
Automatic Power Off 5 minutes
Battery Life: about 3.5 years
Pressure Ranges
-1 to 3 bar, -1 to 5 bar, -1 to 25 bar, -1 to 35 bar, -1 to 100 bar, -1 to 350 bar, -1 to 700 bar
