Homogenizer Pressure Gauge
DH Series
DH Series
Specifications
4 100mm ( 4" ) & 150mm (6") Dial Sizes
4 Glycerin Filled
4 Bottom Direct Mount
4 SS304 Case & Ring IP65
4 SS316 Diaphragm
4 Available with Loose or Pre-installed 1-1/8" Flange
4 Pressure Range: 100 to 700kg/cm2 (other units bar, kpa, psi)
Options Available
4 1-1/8" Flange for Mounting
4 Custom Designed Dials
4 Electric Contacts
4 Accessories: Pulsation Dampner, Syphons, Gauge Cocks, Gauge Savers
4How to Inquire:
Send you inquiry with details like
dial size
pressure range
mounting
mounting flange requirement
or any other special requirements you have.
Send Email to 4 sales@adarshpressuregauge.com or 4Click here to send inquiry by online form Or Call +91-22-29275496 Fax +91-22-29275558
The ADARSH Homogenizer Gauge now lasts longer due to the new design feature incorporated inside the gauge. Generally homogenizer gauge is used in food, dairy industry on Homozenizer Machines. Since it is a hygenic application diaphragm seal is used. Further the presence of continuous pulsating media and that too at High Pressure causes failure of ordinary diaphragm gauges. At Adarsh a diaphragm seal has been specially designed to sustain this high pressure pulsation and vibration. Available upto ranges 700 kg/cm2, bar / 10000 psi.
Dual Scale (kg/cm2 with psi or bar with psi)
kg/cm2 psi
0-106
0-140
0-210
0-280
0-350
0-420
0-560
0-700
Pressure Range Selection
Single Scale
kg/cm2 or bar
0-100
0-160
0-250
0-400
0-600
0-1500
0-2000
0-3000
0-4000
0-5000
0-6000
0-8000
0-10000
Since 1989
For Inquiry CALL +91-22-29275496
India
Address:
Adarsh Industries
307, Shankala Industrial Estate,
Gogatewadi, Off Aarey Road,
Goregaon East,
Mumbai - 400063
India
Tel: +91-22-29275496, Fax: +91-22-29275558
Now Available Ready Stock
4" Dial, Glycerin Filled, 0-420kg/cm2 / 0-6000 psi
