Process Pressure Gauges
EP Series
For Inquiry CALL +91-22-29275496
Email: sales@adarshpressuregauge.com
Dual Scale (kg/cm2 with psi  or bar with psi)

kg/cm2      psi
0-1.06
0-2.1
0-4.2
0-7
0-10.6
0-14
0-21
0-28
0-35
0-42
0-56
0-70
0-106
0-140
0-210
0-280
0-350
0-420
0-560
0-700
0-1060


Pressure Range Selection

Single Scale

kg/cm2 or bar
-1x0
0-1
0-2.5
0-4
0-6
0-10
0-16
0-25
0-40
0-60
0-100
0-160
0-250
0-400
0-600
0-1000

Vacuum & Compound
-1x0
-1x1.5
-1x3
-1x5
-1x9
-1x15
-1x24


0-15
0-30
0-60
0-100
0-150
0-200
0-300
0-400
0-500
0-600
0-800
0-1000
0-1500
0-2000
0-3000
0-4000
0-5000
0-6000
0-8000
0-10000
0-15000
Features

4 4-1/2" dial size
4 Polypropylene Case and Ring
4 Solid Front Design with Full Blow Out Back
4 SS316 Bourdon and Socket, SS304 Movement
4 Dry or Liquid Filled (Glycerin or Silicon)
4 ¼”, ½” npt connection
4 Bottom Direct Mount with 3 hole for fixing
4 Accuracy ±1% F.S.D. , (or ±0.5% F.S.D. )

Download Datasheets                                        Series

115mm (4-1/2") Dial Size Stainless Steel Pressure Gauge.......... EP


Vacuum & Compound

kg/cm2    psi
-1x1
-1x2.1
-1x4.2
-1x7
-1x10.6
-1x14
-1x21

30"Hx15
30"Hx30
30"Hx60
30"Hx100
30"Hx150
30"Hx200
30"Hx300


Other Units: Kpa, Mpa also available
Custom Ranges also available

Applications

Pharmaceutical, Chemical, Petrochemical, Oil & Gas, Refinery, Paper & Pulp, Sugar, Breweries, Food & Beverages, Cement Industries, etc
4How to Inquire:

Send you inquiry with details like dial size, pressure range, connection, mounting, dry or liquid filled or any other special requirements you have.

Send Email to 4 sales@adarshpressuregauge.com or 4Click here to send inquiry by online form Or Call +91-22-29275496 Fax +91-22-29275558
