Schaffer Gauges have a Diaphragm whos displacement is transferred via a link to the movement. They are suitable for low pressure measurement from 0 -400mmwc to 6000mmwc and high side from 0-1 kg/cm2 to 0-25 kg/cm2. Schaffer Gauges are suitable for Pharmaceutical, Chemical, Petrochemical, Oil & Gas, Refinery, Paper & Pulp, Sugar, Breweries, Food & Beverages, Cement Industries, etc
4 Dial Sizes 100mm (4") and 150mm (6")
4 SS316 Diaphragm and Bottom Chamber/Flange
4 3/8â€, Â½â€ bsp / npt connection or Flanged End as per DIN, ANSI, BS Standards
4 Bottom or Back Mounted
4 Accuracy Â±1.6% F.S.D.
4 Flange End Connections as per DIN, ANSI, BS Standards
4 Teflon Coating / Lining on Diaphragm and wetted parts
