Sealed Diaphragm Pressure Gauges
DX Series
DX Series
Applications
Pharmaceutical, Chemical, Petrochemical, Oil & Gas, Refinery, Paper & Pulp, Sugar, Breweries, Food & Beverages, Cement Industries, etc
Features
4 Dial Sizes 100mm (4") and 150mm (6")
4 SS316 Diaphragm and Bottom Chamber/Flange
4 3/8”, ½” bsp / npt connection or Flanged End as per DIN, ANSI, BS Standards
4 Bottom or Back Mounted
4 Accuracy ±1.6% F.S.D.
Options Available
4 Special Diaphragm Material like Tantalum, Hastealloy-C, etc...
4 Teflon Coating / Lining on Diaphragm and wetted parts
4 Electric Contacts 1N0+1NC and others
4 Remote Capillary Seal
Download Datasheets Series
Type 1 : Thread End Connection
100mm/150mm Sealed Diaphragm Pressure Gauge..............DXA
Type 2 : Flange End Connection
100mm/150mm Sealed Diaphragm Pressure Gauge..............DXB
Type 3 : Flange End Connection
100mm/150mm Sealed Diaphragm Pressure Gauge..............DXC
Dual Scale (kg/cm2 with psi or bar with psi)
kg/cm2 psi
0-1.06
0-2.1
0-4.2
0-7
0-10.6
0-14
0-21
0-28
0-35
0-42
0-56
0-70
0-106
0-140
0-210
0-280
0-350
0-420
Pressure Range Selection
Single Scale
kg/cm2 or bar
0-1
0-2.5
0-4
0-6
0-10
0-16
0-25
0-40
0-60
0-100
0-160
0-250
0-400
Vacuum & Compound
-1x1.5
-1x3
-1x5
-1x9
-1x15
-1x24
0-15
0-30
0-60
0-100
0-150
0-200
0-300
0-400
0-500
0-600
0-800
0-1000
0-1500
0-2000
0-3000
0-4000
0-5000
0-6000
Vacuum & Compound
kg/cm2 psi
-1x1
-1x2.1
-1x4.2
-1x7
-1x10.6
-1x14
-1x21
30"Hx15
30"Hx30
30"Hx60
30"Hx100
30"Hx150
30"Hx200
30"Hx300
Other Units: Kpa, Mpa also available
Custom Ranges also available
4How to Inquire:
Send you inquiry with details like dial size, pressure range, connection, mounting, dry or liquid filled or any other special requirements you have.
Send Email to 4 sales@adarshpressuregauge.com or 4Click here to send inquiry by online form Or Call +91-22-29275496 Fax +91-22-29275558
Since 1989
India
Type 3 : DXC
Flanged End
Diaphragm Seal Gauge
Type 1 : DXC
Thread End
Diaphragm Seal Gauge
