Stainless Steel Pressure Gauges
MX Series
MX Series
For Inquiry CALL +91-22-29275496
Dual Scale (kg/cm2 with psi or bar with psi)
kg/cm2 psi
0-1.06
0-2.1
0-4.2
0-7
0-10.6
0-14
0-21
0-28
0-35
0-42
0-56
0-70
0-106
0-140
0-210
0-280
0-350
0-420
0-560
0-700
0-1060
Pressure Range Selection
Single Scale
kg/cm2 or bar
-1x0
0-1
0-2.5
0-4
0-6
0-10
0-16
0-25
0-40
0-60
0-100
0-160
0-250
0-400
0-600
0-1000
Vacuum & Compound
-1x0
-1x1.5
-1x3
-1x5
-1x9
-1x15
-1x24
0-15
0-30
0-60
0-100
0-150
0-200
0-300
0-400
0-500
0-600
0-800
0-1000
0-1500
0-2000
0-3000
0-4000
0-5000
0-6000
0-8000
0-10000
0-15000
Applications
Stainless Steel Gauges are used for corrosive media & challenging ambient environment. These gauges have SS316 wetted parts with SS304 IP65 case and ring. All joints are argon welded. The 4" & 6" models have socket welded to case design which avoids leakages and provides integrity to the gauge. Liquid filling option is available for applications with vibrations.The gauges are widely used in Pharmaceutical, Chemical, Oil & Gas, Paper & Pulp, Sugar, Breweries, Food & Beverages, Cement Industries, etc
Features
4 SS316 Bourdon and Socket, SS304 Movement
4 Stainless Steel SS304 Case and Ring IP65
4 Dry or Liquid Filled (Glycerin or Silicon)
4 Socket Welded to Case (4" & 6" Dial Size)
4 1/8”, ¼”, 3/8”, ½” bsp or npt connection
4 Bottom Direct, Bottom Surface, Back Direct, Back Panel, Back Clamp Mounting
4 Accuracy ±1% F.S.D. for 4", 6" & 10" & ±1.5% F.S.D. for 1½", 2" & 2½" Gauges
Options Available
4 Custom Designed Dials
4 Electric Contacts
4 Accessories: Pulsation Dampner, Syphons, Gauge Cocks, Gauge Savers
Download Datasheets Series
40mm (1-1/2") Dial Size Stainless Steel Pressure Gauge.........MX150
50mm (2") Dial Size Stainless Steel Pressure Gauge...............MX200
63mm (2-1/2") Dial Size Stainless Steel Pressure Gauge.........MX250
80mm (3") Dial Size Stainless Steel Pressure Gauge...............MX300
100mm (4") Dial Size Stainless Steel Pressure Gauge.............MX400
150mm (6") Dial Size Stainless Steel Pressure Gauge.............MX600
200mm (8") Dial Size Stainless Steel Pressure Gauge.............MX800
250mm (10") Dial Size Stainless Steel Pressure Gauge...........MX1000
Vacuum & Compound
kg/cm2 psi
-1x1
-1x2.1
-1x4.2
-1x7
-1x10.6
-1x14
-1x21
760mmhgxx0
30"Hgx15
30"Hgx30
30"Hgx60
30"Hgx100
30"Hgx150
30"Hgx200
30"Hgx300
30"Hgx0
Other Units: Kpa, Mpa also available
Custom Ranges also available
4How to Inquire:
Send you inquiry with details like dial size, pressure range, connection, mounting, dry or liquid filled or any other special requirements you have.
Send Email to 4 sales@adarshpressuregauge.com or 4Click here to send inquiry by online form Or Call +91-22-29275496 Fax +91-22-29275558
