Test / Master Pressure Gauges
ET Series

Specifications

4 Dial Sizes 150mm (6"), 200mm (8") and 250mm
4 Accuracy ±0.5% F.S.D. , ±0.25% F.S.D.
4 Berrylium Copper / SS316
4 High Precision Brass Movement / SS316 Movement
4 3/8”, ½” bsp / npt connection
4 Bottom or Back Mounted

Pressure Range Selection

Single Scale

kg/cm2 or bar
0-1
0-2.5
0-4
0-6
0-10
0-16
0-25
0-40
0-60
0-100
0-160
0-250
0-400
0-600

4How to Inquire:

Send you inquiry with details like
Dial size : 6", 8" or 10"
Pressure range : Any standard range from above in bar or kg/cm2
Connection : 3/8" or 1/2" bsp or npt
Mounting : Bottom or Back
Accuracy Required : ±0.5% F.S. or ±0.25% F.S.

or any other special requirements you have.

Send Email to 4 sales@adarshpressuregauge.com or 4Click here to send inquiry by online form Or Call +91-22-29275496 Fax +91-22-29275558
adarsh industries - manufacturer of pressure gauges, temperature gauges and gauge accessories
Since 1989
India
Test / Master Gauges are used in laboratories, pressure gauge calibration, instrument testing and other applications where accuracy and repeatability is important. Available in ±0.5% and ±0.25% F.S. Accuracy.
